• Compatible with 29T4 and 29TX Power Supplies
• Enables power supply status monitoring and control of two (2) power supply/chargers over a LAN/WAN or USB connection

• UL294 Listed - Access Control System Units
• UL603 Listed - Power Supplies for use with Burglar Alarm Systems
• UL1481 - Power Supplies for Fire Protective Signaling Systems
• cUL Listed for CAN/ULC - s319-05, Electronic Access Control Systems
• cUL Listed for ULC-S318-96 - Power Supplies for Burglar Alarm Systems (also suitable for Access Control)

• Operating temperature: 32°F to 120°F
• Storage temperature: -22°F to 158°F
• Relative humidity: 85% +/- 5%

Current consumption 100mA to be subtracted from the power supply's output

3.3"

• Provides values on demand for AC fault status, DC current and voltage, as well as Battery fault status, and reports conditions via email and Windows Dashboard Alert
• Can also be used as a standalone network controlled relay powered from any 12VDC to 24VDC power supply
• Two separate networked relays can be used for variety of applications, such as: reset an access control system or gate operator, CCTV camera power, trigger camera to start recording, initiate remote test sequence of security system, or trigger HVAC system
• Management interface software included (USB flash drive)
• Management interface for up to two (2) power supply/chargers,
• Three (3) monitored input triggers
• Management interface software included (USB flash drive)
• Includes interface cables and mounting bracket

STATUS MONITORING:

• AC status
• Output current draw
• Unit's temperature
• DC output voltage
• Low batter/battery presence detection
• Input trigger state change
• Output (replay and power supply) state chang

PROGRAMMING:

• Battery service date indication
• Programmable via USB or web browser
• Automated timed events: control output relays and power supply via flexible timing parameter

Reporting:

• Programmable dashboard notifications
• Email notification selectable by event,
• Event log tracks history

Network Communication Diagnostics

One (1) year
