Heavy Duty Commercial

• 2-3/4" (70 mm) Standard
• 2-3/8" (60 mm) Option

• ADA Compliant ANSI A117.1 Accessibility Code
• UL/cUL Listed for all functions up to 3 hours "A" label single doors
• UL10C Positive Pressure Rated
• BHMA Certified ANSI A156.36, Grade 1
• ANSI A250.13 Severe Windstorm Compliant
• Miami Dade County, FL NOA #18-0816.08

• Keyed Different - standard
• Cylinder drilled 6 pin, Keyed 5 pin - standard
• Other Keying options, including 6 pin keyed, available from factory
• Zero bit cylinders will be 6 pin keyed
• SFIC uncombinated or combinated, brass 6 pin or 7 pin cores sold separately

• 1" (25 mm) throw, brass with concealed hardened steel roller
• 1-1/8" x 2-1/4" (29 mm x 57 mm) faceplate

• 1-3/4" - 2" (45 mm - 51 mm) - Standard
• 2-1/4" (57 mm) - Optional for conventional keyed only

Wrought Brass or Bronze

US3, US4, US10B, US26 and US26D

Classroom (E2171)

• SFIC option available (Cores are sold separately - standard)
• Handing is field reversible

• Split Finish
• Additional Deadbolts and strikes available

• 1-1/8" x 2-3/4" (29 mm x 70 mm) no-lip strike standard
• Optional ASA strike available

Lifetime
