Standard Duty Commercial

• 2-3/4" (70 mm) Standard
• 2-3/8" (60 mm) Optional

• ADA Compliant ANSI A117.1 Accessibility Code
• UL/cUL Listed for all functions up to 3 hours "A" label single doors
• UL10C Positive Pressure Rated
• BHMA Certified ANSI A156.36, Grade 2
• ANSI A250.13 Severe Windstorm Compliant
• Miami Dade County, FL NOA #17-1226.23

• Keyed Different - standard
• Cylinder drilled 6 pin, Keyed 5 pin - standard
• Other Keying options, including 6 pin keyed, available from factory
• Zero bit cylinders will be 6 pin keyed
• SFIC uncombinated or combinated, brass 6 pin or 7 pin cores sold separately

• 1" (25 mm) Throw - Brass with concealed hardened steel roller to prevent sawing or cutting
• 1-1/8" x 2-1/4" (29 mm x 57 mm) square corner faceplate

• 1-3/8" - 1-3/4" (35 mm - 45 mm) - Standard
• 2-1/4" (57mm) - Optional for conventionally keyed only

Wrought Brass, Bronze or Stainless Steel

US3, US4, US10B, US26D and US32D

Cylinder x Thumbturn (E2152)

Non-handed

• Split Finish
• Additional Deadbolts and strikes available

• 3930 1-1/8" x 2-3/4" (29 mm x 70 mm) no-lip strike - standard
• 3929 1-1/4" x 4-7/8" (32 mm x 124 mm) ASA deadbolt strike – optional

Lifetime
